OEM 144mm 1200w Bucket Wet And Dry Vac Cleaner Motor With Four Positioning Holes

Our products are central parts of household, industrial vacuum cleaners,
spray guns, hair dryers, garden tools.
  • 144mm 1200w Bucket Wet And Dry Vac Cleaner Motor With Four Positioning Holes
  • 144mm 1200w Bucket Wet And Dry Vac Cleaner Motor With Four Positioning Holes
  • 144mm 1200w Bucket Wet And Dry Vac Cleaner Motor With Four Positioning Holes
  • 144mm 1200w Bucket Wet And Dry Vac Cleaner Motor With Four Positioning Holes
  • 144mm 1200w Bucket Wet And Dry Vac Cleaner Motor With Four Positioning Holes
  • 144mm 1200w Bucket Wet And Dry Vac Cleaner Motor With Four Positioning Holes
Wet and dry vacuum cleaner motor

144mm 1200w Bucket Wet And Dry Vac Cleaner Motor With Four Positioning Holes

  • Highly powerful , Great efficiency for vacuum cleaner motor
  • Very big motor suction Turbine 1800W for wet and dry cleaner
  • Full cooperation , low noise , easily install , more thinker carbon brush
  • Long working life

Product feature

  1. Highly quanlity for Industrial Vacuum Cleaner Motor, Model YH-PR , Input voltage100V to 240V, rated input power 600-1200W, max rpm 22000r/min, rated frequency 50/60Hz, max vacuum degree 28kpa, Max air flow 3.3 M3/min, temperature rise 60K, Noise 89-93dB, spark less than 1, max efficiency 35%.
  2. Pure copper core, low noise operation, high precision rotor, the eccentricity is less than 0.1mm, running smoothly. silicon steel stator with protective paint, all-copper high-precision rotor, and sufficient pure copper wire turns.
  3. Wide range of uses, suitable for various brands such as dyson,karcher.

Product Specification

Patameters/Models

YH-PR

Tolerance Value

Product diameter(mm)

144.5

/

Product height (mm )

158.3-160

/

Rated voltage(V)

100-240

/

Rated frequency(Hz)

50/60

/

Rated input power(W)

600-1200

+10% -10%

Max vacuum degree(KPa)

17-28

-5%

Max air flow(M3/min)

2.5-3.3

-8%

Temperature rise(K)

60-75

/

Noise(dB)

89-93

/

Spark

<Level 1

/

Class of insulation

B、E

/

Max efficiency

35%

-10%

Product drawing
