86mm Portable Low Noise Dry Vacuum Cleaner 500W Universal Motor Custom

Our products are central parts of household, industrial vacuum cleaners,
spray guns, hair dryers, garden tools.
  • 86mm Portable Low Noise Dry Vacuum Cleaner 500W Universal Motor
  • 86mm Portable Low Noise Dry Vacuum Cleaner 500W Universal Motor
  • 86mm Portable Low Noise Dry Vacuum Cleaner 500W Universal Motor
  • 86mm Portable Low Noise Dry Vacuum Cleaner 500W Universal Motor
  • 86mm Portable Low Noise Dry Vacuum Cleaner 500W Universal Motor
  • 86mm Portable Low Noise Dry Vacuum Cleaner 500W Universal Motor
Dry vacuum cleaner motor

86mm Portable Low Noise Dry Vacuum Cleaner 500W Universal Motor

  • 86mm diameter has strong versatility and is suitable for most brands of vacuum cleaners
  • Made of pure copper wire, high-precision rotor, eccentricity less than 0.1mm
  • Both AC and DC available
  • 86mm Portable Low Noise Dry Vacuum Cleaner 500W Universal Motor
  • 86mm Portable Low Noise Dry Vacuum Cleaner 500W Universal Motor
  • 86mm Portable Low Noise Dry Vacuum Cleaner 500W Universal Motor
  • 86mm Portable Low Noise Dry Vacuum Cleaner 500W Universal Motor
  • 86mm Portable Low Noise Dry Vacuum Cleaner 500W Universal Motor
  • 86mm Portable Low Noise Dry Vacuum Cleaner 500W Universal Motor
Message Form Contact Us

Product feature

  1. The most popular style, universal diameter 86.5mm, model no.Model YH-(D-1)，Input voltage 100V to 240V, rated input power 200-600W, max rpm 33500r/min, rated frequency 50/60Hz, max vacuum degree 8-20.6kpa, max air flow 0.7-1.7M3/min, temperature rise 70K, noise 75-92K, spark less than 1, class of insulation B E, max efficiency 34%.
  2. 600watt carbon brush vacuum cleaner motor, pure copper core, low noise operation, high speed rpm, high precision rotor, the eccentricity is less than 0.1mm, running smoothly.
  3. This product can also be made into DC voltage 12V 24V 36V 48V.
  4. Wide range of uses, vacuum imp cleaner,whall cordless vacuum cleaner,bagged upright vacuum,dc motor vacuum cleaner.

Product Specification

Patameters/Models

YH-(D-1)

Tolerance Value

Product diameter(mm)

86.5

/

Product Height (mm )

96.5

/

Rated voltage(V)

100-240

/

Rated frequency(Hz)

50/60

/

Rated input power(W)

200-600

+10% -10%

Max vacuum degree(KPa)

8-20.6

-5%

Max air flow(M3/min)

0.7-1.7

-8%

Temperature rise(K)

≤70

/

Noise(dB)

75-92

/

Spark

<Level 1

/

Class of insulation

E

/

Max efficiency

34%

-10%

Product drawing
